| Feature | Specifications |
| Power Supply | Power Adaptor, 52V/2.5A |
| PoE Port | 8×10/100 Mbps |
| Uplink Port | 2×10/100/1000 Mbps |
| Network Standard | IEEE802.3, IEEE802.3u, IEEE802.3X |
| PoE Standard | IEEE802.3af/at |
| Backplane Bandwidth | 5.6Gbps |
| Forwarding Capacity | 4.16Mpps |
| Packet Buffer | 1792K |
| MAC Address List | 4K |
| Forward Mode | Store-and- forward |
|
Mode Switch |
Default: All port can be communicated freely |
| Extend: Port 1-8, Speed 10Mbps, Maximum transmission distance up to 250 meters,Port 1-8 are isolated respectively, but can communicate with Port 9-10 | |
| PoE Power Mode | End-span 1/2(+),3/6(-) |
| PoE Power Budget | Each port ≤30W Whole device≤130W |
|
Protection |
Surge Protection: 4KV (common mode),10/700us IEC61000-4-5 |
| ESD Protection: Contact Discharge: ±4KV
Air Discharge: ±6KV Standard: IEC61000-4-2 |
|
| Operating Temperature | -20~55℃ 5%-95% (non-condensing) |
| Storage Temperature | -40~75℃ 5%-95% (non-condensing) |
| Dimensions (L*W*H) | 220mmx100mmx26mm |
| Weight | 650g |
| Mean time between failures (MTBF) | ＞50000h |
| Certification | CE,FCC,BIS,ROHS |
Poe Switch
POE Switch 8 (10/100)+2 (10/100/1000)
+ Free Shipping-
-
-
The 8 Port PoE Switch(FYR-82GE ) provides 8-port 10/100Mbps IEEE 802.3af/at Power over Ethernet with a total of 130 watts of PoE budget, which is an ideal solution to fulfill the demand of sufficient PoE power for network applications. It is able to drive 8 IEEE 802.3af/at compliant powered devices. It has 2 Uplink Port(10/100/1000).
- 8×10/100Base-TX PoE ports and 2×10/100/1000 Base-TX uplink ports
- Comply with IEEE802.3, IEEE802.3u, IEEE802.3af/at standards
- Internal 52VDC/2.5A power adapter
- Support desktop and wall mount installation
- Plug and play, no need to configure
- Support two operating modes extend with VLAN isolated, default configuration
- Support 4KV surge protection, 6KV ESD protection
-
-
